Flow Through Cells
A variety of flow through cells in different configurations for fluorometric experiments where a constantly flowing sample can be passed through the observation chamber. Each fluorescence cell has 90º windows optically polished for excitation and emission.
Type 74FL Micro Fluorescence Flow Through Cell (Lightpath: 2mm)
Type 74FL Micro Fluorescence Flow Through Cell (Lightpath: 2mm)
Firefly's micro fluorometer flow cell with a 2mm lightpath. Four sides of the optical chamber are polished.
Features of FireflySci Type 74FL Micro Flow Through Cell:
- Highly accurate results, only need to test sample once.
- Premium quality: Firefly cuvettes are made with the best quality quartz and glass material available. Excellent transmission values.
- Made by hand, ensuring high quality optical polishing with no defects.
- Each cell goes through a rigorous inspection process before leaving our factory.
- Fire-fused to ensure that cuvettes are robust and durable.
- Comes in several different materials: (UV Quartz and IR Quartz)
- Available in 2mm lightpath.
- Four windows optically polished.
Lightpath | Top | Outer Length | Outer Width | Outer Height | Chamber Length | Chamber Width | Capacity |
---|---|---|---|---|---|---|---|
2mm | Flow Through | 3.0mm | 3.0mm | 7.6mm | 2.0mm | 2.0mm | 30µl |
Related Academic Reading:
![Applied Optics- December 1984](https://images.squarespace-cdn.com/content/v1/5411d5c0e4b02e1c8b27565a/1467149800945-5BTVB5JXRZN5P46NAZF9/Applied+Optics-+74UV2.jpg)
Silicone tubing for connecting to quartz tube flow through cells
